Flexible and Creative LED Display
| Model | Indoor LED Sphere | Outdoor LED Sphere | ||||||||||
| Pixel Pitch(mm) | 1.5 | 1.86 | 1.875 | 2 | 2.5 | 3 | 3 | 4 | 5 | 6 | 5 | 10 |
| Diameter(m) | 1.5/2 | 4 | 3.2 | 0.3/1/1.2/1.5/1.8/2/3 | 0.6/0.8/1/1.2/1.5/1.8/2/2.5/2.8/3/5 | 0.6/0.8/1/1.2/1.5/1.8/2/2.5/4.2 | 3/3.5/5/5.5/6 | 0.6/0.8/1/1.2/1.5/1.8/2/2.2/2.5/3/3.54/5 | 1/1.2/1.5 | 2.5/3/6 | 1.5 | 3 |
| Pixel Density(dots/Sqm.) | 443556 | 288369 | 284089 | 250000 | 160000 | 111111 | 111111 | 62500 | 40000 | 27777 | 40000 | 10000 |
| Pixel Configuration | SMD1212 | SMD1010 | SMD1010 | SMD1415 | SMD1415 | SMD1415 | SMD1415 | SMD2121 | SMD2121 | SMD2121 | SMD2727 | SMD3535 |
| Brightness(cd/Sqm.) | 600~800 | ≥5500 | ≥6000 | |||||||||
| Scan | 40 | 64 | 64 | 30 | 24 | 22 | 32 | 16 | 16 | 16 | 40 | 64 |
| Power Con. (Max/Avg) | 800/300W/Sqm. | 1200/600W/Sqm. | ||||||||||
| Service Access | Front | Front / Rear | ||||||||||
| Refresh Rate(HZ) | 3840 | 3840 | ||||||||||
| Grey Scale(bit) | 14bit | 14 | ||||||||||
| View angle | 360° | 360° | ||||||||||
| IP Rate | IP31 | IP65 | ||||||||||
| Operation Temperature | -20℃~60℃ | -20℃~60℃ | ||||||||||
| Input Voltage(AC) | 100/240V | 100/240V | ||||||||||
* Specifications and photos are subject to change without prior notice.
