Flexible and Creative LED Display
| Model | P1.25 | P1.579 | P1.667 | P1.875 | P2 | P2.5 | P3 |
| Pixel Pitch(mm) | 1.25 | 1.579 | 1.667 | 1.875 | 2 | 2.5 | 3 |
| Pixel Matrix Per Sqm. | 640000 | 401111 | 360000 | 284444 | 250000 | 160000 | 111111 |
| Pixel Configuration | SMD1010 | SMD1010 / SMD1212 | SMD1010 / SMD1212 | SMD1212 / SMD1515 | SMD1515 | SMD1515 | SMD1515 / SMD2121 |
| Brightness (nits) | ≥600 | ≥650 | ≥700 | ≥750 | ≥750 | ≥750 | ≥900 |
| Scan | 1/48 | 1/38 | 1/36 | 1/32 | 1/30 | 1/24 | 1/20 |
| Module Dimension | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft | 240x120mm / 0.79×0.39ft |
| Module Material | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket | Silicon Rubber Soft Bracket |
| Module Weight | 0.215kg | 0.203kg | 0.195kg | 0.216kg | 0.205kg | 0.175kg | 0.175kg |
| Power Con. (Max / Avg) | 1000 / 340 w/sq.m | 1000 / 340 w/sq.m | 800 / 270 w/sq.m | 800 / 270 w/sq.m | 800 / 270 w/sq.m | 800 / 270 w/sq.m | 800 / 270 w/sq.m |
| Service Access | Front | Front | Front | Front | Front | Front | Front |
| Refresh Rate (HZ) | 3840 | 3840 | 3840 | ≥2880 | ≥2880 | ≥1920 | ≥1920 |
| Grey Scale (bit) | 14 | 14 | 14 | 14 | 14 | 14 | 14 |
| Viewing Angle (H/V) | 140 / 140 | 140 / 140 | 140 / 140 | 140 / 140 | 140 / 140 | 140 / 140 | 140 / 140 |
| IP Rate | IP45 | IP45 | IP45 | IP45 | IP45 | IP45 | IP45 |
| Operation Temperature | -10° ~ 50° | -10° ~ 50° | -10° ~ 50° | -10° ~ 50° | -10° ~ 50° | -10° ~ 50° | -10° ~ 50° |
| Input Voltage (AC) | 100V or 240V | 100V or 240V | 100V or 240V | 100V or 240V | 100V or 240V | 100V or 240V | 100V or 240V |
* Specifications and photos are subject to change without prior notice.
Maximum curved angle is 90 degree.
